Engine 1,8 NB natural aspirated Stage 2

Engine 1,8 NB natural aspirated Stage 2

€10,963.87 *

Prices incl. VAT plus shipping costs

delivery in approx. 2-6 weeks

  • KM-NB-18-SA-190
1,8 NB engine for building a natural aspirated engine ( ITB kit  required). By... more
Product information "Engine 1,8 NB natural aspirated Stage 2"

1,8 NB engine for building a natural aspirated engine (ITB kit required). By choosing the right components you can reach up to 190 HP. For consultation to choose the right components do not hesitate to contact us. When you buy the engine the engine is going to be delivered by carrier to you home or you can pick it up at our shop. Building the engine includes the following steps:

Engineblock:

  • Engineblock drilled and fine honed
  • Crankshaft aligned, heaved and fine polished
  • Engine block sealings installing



Cylinder head:

  • Cylinder head dismantle
  • Cylinder head leveled
  • Cylinder head edited
  • Grind valves new
  • valve seats milled
  • Valves fitted
  • Adjust valves clearance



In the interior if the engine we fit the following parts:





In addition to those parts you get a complete Mazda original sealing kit for the engine. This includes the following parts:







  •  16 valve seals
  • 1 cylinder head cover gasket
  • 1 cylinder head gasket
  • 1 sealing crankshaft front
  • 2 sealings camshaft
  • 1 intake manifold gasket
  • 1 exhaust manifold gasket
  • 1 thermostat gasket rear
  • 1 gasket water pump to noozle
  • 2 oil pan sealings (front and rear)
  • All sealings for timing belt cover
  • 1 sealing crankshaft rear
  • 1 O-ring water pump
  • 1 gasket water pump to engine block
  • 1 O-ring thermostat noozle
  • 1 gasket oil strainer





Engines are traded on exchange. It is possible, to buy the engine as a do it yourself package, so you get all the parts ou need to build the engine on your own. In this case, you have to get all the work on cylinderhead and engine block done by an professional engine builder.



To swap on this engine we also recommend the following applications:

Oil cooler kit

Mishimoto radiator NB

ECU (part of our ITB kits)

Wideband lambda AEM

Hardened engine mounts from the mazdaspeed
